Automotive Cold Medium Sensors Performance Index
􀁺 Pressure Range (MPa) : 0～0.98MPa/0～3.33MPa
􀁺 Overload : 5MPa
􀁺 Test Medium: R22 R407C
􀁺 Excitation Voltage (V DC): 5±5% V DC
􀁺 Output Voltage (VDC): 0.5～3.5VDC/0.5～3.9VDC
􀁺 Combined Error (%FS): ±2%FS
􀁺 Insulation Resistance (MΩ): 100MΩ/500VDC
􀁺 Screw Down Moment (N.m): 14.2～17.2 N.M
􀁺 Operation Temperature (℃): －30～105℃
􀁺 Humidity (%RH): <95%RH
􀁺 MediumTemperature (℃): －40～135℃
􀁺 Storage temperature(℃): －40～125℃
􀁺 Load Resistancem (kΩ): >10kΩ
􀁺 Dissipation (mA): <10mA
Note: Output Voltage changes along with Excitation Voltage change.
