FEATURES
􀁺 0 to +450 psi G/A; 0 to +3 MPa G/A; 0 to +30 bar A/G
􀁺 1.0％FS Total Accuracy
􀁺 MEMS technology
􀁺 Programmable ASIC to meet customer specifications
􀁺 Low part count enhances reliability
􀁺 Amplified and temperature compensated
􀁺 EMI protection
DESCRIPTIONS
Model 631 incorporates MEMS technology and custom Application Specific Integrated Circuit (ASIC) technology in the design. It is specifically designed for tough automotive application. Model 631 is designed to perform in the underhood harsh environment such as temperature extremes, vibration, thermal and mechanical shock, and corrosive chemical.
SENSOR SPECIFICATIONS
Electrical:
Supply Voltage 5.0 ± 0.5VDC
Supply Current 10mA max
Maximum Output Current Source 1 mA
Output Impedance 10 ohms max
Output Type radiometric
Output Voltage 0.5 to 4.5 V dc at 5VDC excitation
Operating Characteristics:
Range 0 to +450 psig/a;
0 to +3 MPaG/A;
0 to +30 barA/G
Proof Pressure 200%FS
Total Accuracy (%FS) 1.0%
