Intake Manifold Absolute Pressuer Sensor (611)

FEATURES

● 0.2 bar to 1.0 bar 0.2 bar to 2.0 bar 0.2 bar to 3.0 bar
● 1.5％FS Static Accuracy
● MEMS technology
● Programmable ASIC to meet customer specifications
● Low part count enhances reliability
● Amplified and temperature com
● EMI protection
● Available for turbo applications pensated

DESCRIPTIONS

Model 611 incorporates MEMS technology and custom Application Specific Integrated Circuit (ASIC)Technology in the design. It is specifically designed for tough automotive application.
Model 611 is designed to perform in the underhood harsh environment such as temperature extremes,vibration, thermal and mechanical shock, and corrosive chemical. Typical applications include manifold absolute pressure (MAP), barometric, EGR pressure and brake boost. Please contact us for special design to meet your requirements.

SENSOR SPECIFICATIONS

Electrical:
Supply Voltage 5.0±0.5 VDC
Supply Current 10 mA max
Maximum Output Current Sink 1 mA
Source 0.1 mA
Output Impedance 10 ohms max
Output Type ratiometric
Output Voltage 0.25 to 4.85 VDC at 5VDC excitation
Sensor Operating Characteristics:
Range 0.2 bar to 1.0 bar
0.2 bar to 2.0 bar
0.2 ba r to 3.0 bar
Proof Pressure 200%FS
Static Accuracy (%FS) 1.5 typ.
